DUST FREE PULVERIZING

Description

Lab Pulverizing Mill

TR-LPM2000 laboratory pulverizing mill is ideal for applications requiring grinding of hard, brittle, dense, and fibrous materials to final fineness for analysis, and features the benefits of dust-free, fine grinding, and no sample loss.

Finely ground dust-free Lab Pulverizing Mill TR-LPM2000

Lab Pulverizing Mill TR-LPM2000 laboratory pulverizing mill is ideal for applications requiring grinding of hard, brittle, dense, and fibrous materials to final fineness for analysis, and features the benefits of dust-free, fine grinding, and no sample loss.

Standard Features

1. Suitable for materials such as ores, minerals, ferroalloys, ceramics, soils, aggregates and chemicals.
2. Ideal for mineral laboratories that prepare large samples on a regular basis.
3. Benefits those remote laboratories that do not need perform a special maintenance on integral vibration motor drives.
4. Universal drive shaft provides more power to vibratory head and optimize motor life.
5. Trouble-free bowl clamp features a unique quick, easy and non-loosening pneumatic airbag bowl clamping design.
6. Grinding bowl sizes consist of 300cc, 400cc, 800cc, 1000cc and 2000cc.
7. 40g up to 1600g can be ground at once.
8. Samples can be milled to 95% passing 75 microns within 3 minutes.
9. A lid locking safety switch makes the chamber inaccessible during operation. It incorporates a time delay to prevent the operator from accessing the mill platform until the machine has completely stopped.
10. The mill will not start until the lid is completely closed.
11. The machine can be stopped quickly with the easily accessible emergency stop button.
12. Dismountable design of front panel offers easy and convenient maintenance.
13. Bowl Jack pneumatic lifting device allows for less manpower and ensures better efficiency.
14. Sturdy cabinet with rubber gasket provides dust-free and environmentally friendly operation and performance.

TR-LPM2000 Laboratory Pulverizing Mill Technical Parameter

Voltage

380-415V 50Hz 3phase

Compressed Air Requirements

500 kPa to 600 kPa at 1L per minute maximum flow

Motor Power

2.2kW

Compatible Grinding Bowls

300cc 400cc 800cc 1000cc 2000cc

Feed Size

≤20mm

Bowl Materials

Standard steel, Chrome steel, Tungsten carbide

Output Size

95% 75μm

Mill Net Weight

360kg

Timer Setting

1 second-99 hours

Mill Dimensions

1180x1480x700mm

Grinding Capacity

40g-1600g
